Self Cleaning Screens
Compare with traditional woven wire screens,wire self cleaning screens efficient screening all kind size of the most wet,moist material using in mining,quarry,aggregate processing industires,no blinding screening, increase production.
Advantanges Of Self Cleaning Screens:
- Stable structure
- Accurately aperture size
- Wear and abrasion resistant
- Great self cleaning screening capacity
- Anti blinding & clogging screening
- Suit for wet, moist,sticky and other difficult material screening,
- Promote prouction
Candurs provide D mesh,W mesh,H mesh of self cleaning screens to meet customer's special screening required.
Wire Material:
- High carbon steel
- High tensile spring steel
- Stainless steel
D-Mesh,W mesh,H mesh-Self Cleaning Screens:
Standard Self Cleaning Screens List:
Aperture | Wire Diameter (mm) | Aperture | Wire Diameter (mm) | ||||
---|---|---|---|---|---|---|---|
(mm) | Light | Middle | Heavy | (mm) | Light | Middle | Heavy |
2.5 | 1.25 | 9.0 | 2.5 | 3.15 | |||
2.75 | 1.6 | 9.5 | 2.5 | 3.15 | |||
3.0 | 1.6 | 10.0 | 2.5 | 3.15 | |||
3.15 | 1.6 | 2.0 | 11.2 | 2.5 | 3.15 | ||
3.5 | 1.6 | 2.0 | 12.7 | 3.15 | |||
4.0 | 1.6 | 2.0 | 13.2 | 3.15 | |||
4.75 | 1.6 | 2.0 | 2.5 | 14.0 | 3.15 | ||
5.0 | 1.6 | 2.0 | 2.5 | 15.0 | 3.15 | ||
5.6 | 2.0 | 2.5 | 18.0 | 3.15 | |||
6.0 | 2.0 | 2.5 | 19.0 | 3.15 | |||
6.3 | 2.0 | 2.5 | 20.0 | 3.15 | |||
7.1 | 2.0 | 2.5 | 3.15 | 22.4 | 3.15 | ||
7.5 | 2.5 | 24.0 | 3.15 | ||||
8.0 | 2.0 | 2.5 | 3.15 | ||||
Customized self cleaning screens panel width and length |
Ordering self cleaning screens:
- Material
- Mesh style
- Wire diameter ( d )
- Supplied ( D ) if asked W-Mesh
- Aperture ( W )
- Panel size
- Supplied drawing if necessary
